Product Details
＋
| Product Features: |
- This product can be easily connected to the PC, mobile phone, PDA by WiFi,
- It can achieve long-distance transmission of HIFI grade audio.
- It also supports multiport lossless digital audio and analog audio output at the same time. You can connect any power amplifier.
- Supports 1x optical and 1x coaxial digital audio outputs.
- Supports 1x RCA analog audio output and 1x headphone output.
- Support HIFI and lossless Music.
- Support multi audio formats and MTV or other video formats playback.
- Support SPDIF 2.1/5.1 sound channel.
- Support Dolby/DTS bit stream transmission, and decoding output stereo analog audio.
- 1x USB2.0 interface, Support AirDisk (WiFi Storage)
- Support internet radio and online music from internet.
- Supports DLNA, Airplay, Qplay and EZcast.
- Support multiple operating systems, e.g. Win XP, Win Vista, Win7/8, Windows Phone, Android, iOS, Mac OS etc.
- Support online firmware update and our supplier will put them into development roadmap.
- Multi language menu
- Applications
- 1. AP Mode (Access Point)
- In this mode, the phone/PC directly connected to the decoder, no need connect to the router or
- network. The Default SSID is "WiFi_Music#XXXXX" and password is "00000000".
- 2. Concurrent Mode
- 3. 3G/4G Mode
- In this mode, you can play online music or internet radio through the 3G/4G mobile network of
- mobile phone. You need to create and start a portable WLAN AP before using it.
| Product Specifications: |
| Type: | WiFi Audio Receiver |
| Support System: | iOS, Android, Windows, Mac OS |
| Main Color: | Black |
| Support audio format | MP3, AAC, WAV, FLAC, APE, WMA, DTS, AC3, M4A |
| Wireless Frequency range | 2.4—2.4835GHz |
| Wireless transmission rate | 150Mbps |
| Wireless transmit power | 15dBm (MAX TX) |
| Wireless transmission distance | 100m (no obstacle) |
| DAC Decoding ability | 24 Bit / 96KHz |
| SPDIF coaxial output level | 0.5V p-p |
| L/R output level(1kHz@0dB) | 2V RMS |
| Headphone output power (1kHz@0dB RL=16) | 20mW |
| SNR @ 0dB(CCIR/ARM) | 92dB |
| THD N(-6dB input) | -85dB |
| Frequency response | 20Hz~20KHz |
| Max working current | 430mA |
| Power adapter format Input | AC 100V——240V 50HZ/60HZ; DC5V/1A |
| Operating Temperature range | 0 to 40 Celsius |
| Storage Temperature range | -20 to 60 Celsius |
| Operating Humidity range | 10 to 90%RH (No Condensation) |
| Storage Humidity range | 5 to 95%RH (No Condensation) |
| Net Weight: | 219 g / 7.72 oz |
| Size: | 138 x 64 x 22 mm / 5.382 x 2.496 x 0.858 inch |
| Package Contents: |
- 1 x WiFi Audio Receiver
- 1 x Antenna
- 1 x Power Adapter Note: Right plug of adapter would be sent according to your shipping country
- 1 x English/Chinese Manual
